MLA23A15-1378S0250-C3-S03

Motorized Lead screw Actuator, NEMA 23, 0.00689 英寸 Travel/Step, 2.5 英寸 Stroke, 1/4-20 x 0.500 in Male Thread End Mounting, Single Stack, 1.55 A

Motor comes standard with ?ying leads
Cover tube length (L) = stroke (S) + 1.74 in. (44.2 mm).
Actuator configurations are able to withstand some radial and moment loading due to the bushing design included inside the assembly.
噪音更低。

Dimensions

Specifications	價值
Current per Phase	1.55 A
Motor, End Play	0.002 in @ 2 lb
Motor, Frame Size	NEMA 23
Motor, Insulation Resistance	100 Mohm @ 500 VDC
Motor, Radial Play, Max	0.001 in @ 1 lb
Self-locking	否
Series	Actuator
Temperature Max	125 °F
Temperature Min	15 °F
Voltage per Phase	3.77 直流電壓伏特
Weight	1.8 lb
磁線絕緣	Class B 266 °F
導桿與軸的安裝同心度（TIR）	0.003 英寸
電感	4.2 mH
電阻	2.43 Ω
堆棧類型	Single Stack
功率損耗	5.84 W
介電強度	500 VAC for 1 minute
濕度，最大值	85 %
溫度，存儲	-4 to 122 ºF
溫度，外殼 - 最大值	176 °F
軸與安裝面的垂直度（TIR）	0.003 英寸
轉動慣量	1.04 oz-in²
